Product Description
It's a large, open-top container for collecting and transporting heavy, wet, or bulky waste (like construction debris, dirt, mud, or demolition material), combined with a hook lift truck for loading and unloading.
All kinds of Hooklift Bins / Roll on or off containers can be designed and manufactured here in Hero Equipment. Usually standard sizes from 4.5 cubic meter to 35 cubic meter can be recommended, besides customized bins can also be achieved according to your designs or requirements.
Normally we use Q235 or Q345 as the materials to build the bins, but if you have special requirements on higher grade of steel, we can also source for you.
Regarding the surface treatment, we can paint the bins in your color or in H.D.G (4 cubic meter to 20 cubic meter only). In addition, extra steel lids , Flat tray and hooklift container can also be provided here, we welcome you to contact us for more information.
Product Parameters
Material | mild steel , in China we usually use Q235, which similar to grade 250(AUS), A283(USA). we can also use Q345, which similar to grade 350 (AUS), A210(USA). |
Thickness of plates used | 10 gauge 8 gauge (3mm-4mm) M/S plate for sides and 8 gauge 6gauge(4mm-5mm) M/S for floor. Thicker plates are available to your requirements
|
Other specifications | 1). RHS are used for top rails, and top edge of plate continuous welded to RHS 2). Fully and partly welded inside and outside 3). Hook bar: Dia 50mm 4). Bottom chassis : PFC or 'I' beam, usually 200*75 PFC 5). Curved sides are available 6). Hinge and rollers with grease points |
Options | 1) Two opening door 2) Up opening door 3) HDG (Hot dipped galvanizing) 4) Crane eyes on top 5) Double opening door 6) Ladder in front or in the back 7) Lids |
Painting | We will paint each bin you order in your company colours, enhancing your company image with great looking bins. Two times of primer + two times of top coat Primer : zinc-based epoxy (Grey) Top coat : Urethane (Any color) |
Product Feature
-Open Top: Allows for easy, high-volume loading from above with machinery.
-Heavy-Duty Construction: Made from high-tensile steel to withstand heavy loads (e.g., dirt, concrete, asphalt, mud) and rough handling.
-Reinforced Corners & Edges: Extra steel at points of stress (where the hook engages and where it rests on the truck).
-Sloped Front End: Designed to match the angle of the truck's hook lift frame for smooth loading.
-Lifting Pockets / Hook Points: Reinforced sleeves or bars under the front of the bin where the truck's hook engages.
-Drainage Holes (often): Small holes in the bottom to allow liquids (like rainwater or slurry from mud) to drain out, reducing transport weight.
-Multiple Sizes: Commonly range from 10 to 40 cubic yards in capacity.
-Hydraulic cover：Easily open the steel lid.
Product Application
Construction Sites: For soil, clay, mud, rubble, and general debris.
Demolition Projects: To haul away broken concrete, bricks, and wood.
Landscaping & Excavation: Removing spoils (dirt and mud) from digging.
Municipal Projects: For drainage ditch clean-out (mud and silt).
Industrial Clean-ups: Where heavy, wet waste is generated.
Our Factory
Our Certificates
For more information : sale@heroeq.com
FAQ
1、Q: Are you a factory or trading company?
A: We are a factory with exporting license.
2、Q: Where is your factory located? How can I visit it?
A: Our factory is located in Yangzhou City, Jangsu Province, China, which is about 350 kms far from Shanghai. You can take the high-speed rail from Shanghai to Yangzhou, we can pick you up there. And there are other ways to come to our company, we can talk more talk if you can contact us. In one word, we can do more to make it easier to visit us.
3、Q: What does your factory do regarding quality control?
A: 1) All raw material we used are environmental-friendly;
2) Skilled workers are used in crucial production process
3) Quality Control Department will check all process like raw material, cutting sizes, parts welding, fully welding and the finished products to make sure they can meet the quality.
4、Q: What service can I get from Hero Equipment (Yangzhou ) Co.,Ltd ?
A: 1) Quick responses with full attention within 24 hours.
2) Customized bins are accepted.
3) Updated production status
4) Short delivery time: some orders can be finished within 15 days, but usually within 30 days.
5) Service before and after sales.
5、Q: Can you design for us?
A: Yes, we can. We have our Tech Dpt.. We can customized design and produce the bins as per customer's requirement.
6、Q: What is your terms of payment?
A: Usually we need 30% as deposit, and balanced will be paid after sending you the scanned copy of documents like B/L, Invoice packing list and so on.
